Belden 8760 (1 parr) 18 AWG (16×30) TC

Deskripsi

• Belden 8760 (1 pair) 18 AWG (16×30) TC, (1) 20 AWG (7×28) TC Drain Wire, PO/PVC, Foil Shld

• Cable Type: Multi-conductor, shielded

• Conductors:

  • 1 pair of 18 AWG (16 strands of 30 AWG tinned copper wire each)

  • 1 drain wire: 20 AWG (7 strands of 28 AWG tinned copper)

• Shielding: Aluminum foil shield (100% coverage) with drain wire for grounding

• Insulation: Polyolefin (PO)

• Jacket: PVC (Polyvinyl Chloride)

• Jacket Color: Commonly gray (but may vary)

• Rating: CM (Communications cable, per NEC Article 800)

• Voltage Rating: 300V

• Temperature Rating: Up to 60°C (sometimes up to 75°C, depending on version)

• Impedance: ~93 Ohms (for RS-232 and similar signaling)

• Capacitance: ~31 pF/ft between conductors

• UL Listing: CM (Communications Multipurpose)
